M/V HUA WANG |
|
6,120BHP AHTS |
| |
|
 |
|
|
|
|
REGISTRATION |
|
|
Flag: |
Liberia |
|
Home Port: |
Monrovia |
|
Builder: |
Jiannan Shipyard, Shanghai |
|
Yard Number: |
H2151 |
|
Year Built: |
1984 |
|
Classification: |
DNV @1A1 Tug and Supply Vessel SF |
|
Call Sign: |
E L R S 7 |
|
Sailing Area: |
World-wide |
|
|
|
|
DIMENSIONS |
|
|
Length Overall: |
58.60 M |
|
Length P.P.: |
51.60 M |
|
Breadth Moulded: |
13.00 M |
|
Depth Moulded: |
6.75 M |
|
Draught Summer: |
5.39 M |
|
Freeboard: |
1.36 M (In Summer Draught) |
|
|
|
|
TONNAGE |
|
|
Gross Tonnage: |
1299 Tons |
|
Net Tonnage: |
487 Tons |
|
Light Ship: |
1188.95 Tons |
|
Dead Weight: |
1868.57 Tons |
|
|
|
|
DECK CAPACITIES |
|
|
Deck Area (Clear): |
29.90 M x 10.50 M = 313.95 M2 |
|
Crash Rail: |
2.00 M |
|
Deck Cargo: |
500 Tones |
|
Deck Strength: |
5 T/M2 |
|
|
|
|
DECK EQUIPMENT |
|
|
Anchor: |
2 x 1600 KG |
|
Anchor Chain: |
Dia.34mm, K3, 400M each |
|
Windlass: |
Hydraulic, 45 kW, 30 Bar |
|
Tugger Winch: |
1 x 10 tons |
|
Capstan: |
2 x 5 Tons (Electro-Hydraulic) |
|
Crane: |
1.5 Tons x 5.0M |
|
|
|
|
TANK CAPACITY |
|
|
Fuel oil: |
567.09 M3
|
|
P. Water: |
422.86 M3 |
|
D. Water: |
438 M3 |
|
Bulk: |
1 x 48 M3 + 3 x 50
M3, Total:
198 M3 |
|
Liquid Mud: |
214 M3 (1,345 US
Barrels) |
|
|
|
|
TRANSFER RATES |
|
|
Fuel Oil: |
210 M3/hr, 7.5
Bar |
|
P. Water: |
200 M3 /hr, 7.5
Bar |
|
D. Water: |
1 x 110 M3 /hr + 1
x 49 M3 /hr
, 7.5 Bar, Screw type electric. |
|
Bulk: |
About 60 M3/hr, 60 psi (4.2 bar). |
|
|
Compressors: 2 x Max. 7.5 bar, 15.2 M3/min. |
|
Liquid Mud: |
62 M3/hr |
|
|
|
|
MACHINERY |
|
|
Main Engine: |
2 Sets: BERGEN Diesel Type: KVMB-12 |
|
Horse Power: |
2 x 3,060BHP, Total 6,120BHP |
|
Bollard Pull: |
74 Tons (Certified) |
|
Propeller: |
2 x Ulstein CPP Propellers in Kort Nozzles |
|
Auxiliary: |
2 Sets: COMMINS NT 855-G2 2 x 355BHP |
|
|
1 Set: COMMINS N-495 78 kW |
|
Generator: |
2 x Siemens IFC 4316 B3/B5-, each 170 kW (Diesel) |
|
|
2 x Siemens IFC 5406, each 520 kW (Shaft) |
|
|
1 x Harbour generator: IFC4 256, 85 kW |
|
|
Total: 1,465 kW |
|
Bow Thruster: |
500 BHP, 6.0 Tons |
|
|
|
|
SPEED & CONSUMPTION |
|
|
Maximum: |
13 knots 23 Tons/day |
|
Economical: |
11.0 Knots 10.5 Tons/day |
|
In Port: |
0.6 Tons/day |
|
|
|
|
TOWING / ANCHOR HANDLING Replica Rolex Deepsea Sea-Dweller
|
|
|
Winch: |
Hydraulic Brattvaag SL150W/BSL150W, SWL 150 Tons, Brake Load 200 Tons,
Double Drum. |
|
Tow Line Drum Capacity: |
Dia. 56MM x 1000M |
|
Anchor Handling Wire Drum Capacity: |
Dia. 56MM x 1000M |
|
Shark Jaw: Replica Audemars Piguet Royal Oak Offshore Diver
|
Ulstein Type: AHT052 with local control |
|
Towing Pins: |
2 x Ulstein ? Bridge control |
|
Towing Hook: |
Quick Release, SWL: 60 tons |
|
Rig Chain: |
1 Gypsy wheel on starboard side of the drum, Capacity: 3?? |
|
Chain Locker: |
Nil. |
|
Stern Roller: |
Dia.1.75 M x 3.65 M |
|
|
|
|
NAVIGATION/COMMUNICATION |
|
|
Gyro Compass: |
Robertson SKP-82 |
|
Auto Pilot: |
Robertson AP-8 |
|
Echo Sounder: |
JRC JFE-570S |
|
Radar: |
1 x JRC Type: JMA-527-6 |
|
|
1 x Recal-Decca Type: Bridge Master |
|
Log: |
180-2, Made in China |
|
Radio Direction Finder: |
JRC JLR-1003C ADF |
|
Satellite Navigation: |
GPS Koden KGP-912 |
|
Weather Fax: |
Furuno DFAX FA207 |
|
SSB: |
JRC JSB-176 |
|
VHF: |
2 sets: JRC Type: NCE-2211 |
|
Navitex Receiver: |
JMC NN-900 |
|
|
|
|
SAFETY EQUIPMENT |
|
|
Ring Buoys: |
8 |
|
Life Jackets: |
40 |
|
Work Vests: |
10 |
|
Life Raft: |
2 x 25 persons + 2 x 20 persons |
|
Rescue Boat: |
1 x 6 persons, Zodiac with outboard engine |
|
Rescue Net: |
One rescue net on each side of the vessel. |
|
Fire Fighting: |
300 M3/Hr with one monitor on the top of the bridge. |
|
Anti-pollution: |
2 x Oil dispersant system: 1 boom on each side with 5 spray nozzles; the
system connected with Oil dispersant drums on the deck. |
|
|
No proportion pump and storage tank onboard. |
|
Emergency Radio: |
Yes |
|
Emergency Life Buoy Marker: |
Yes |
|
Radio Distress Transmitter: |
Yes |
|
|
|
|
PROVISION |
|
|
Accommodations: |
6 x single, 4 x double, 1 x 3 persons and 1 x 12 persons |
|
|
Total: 29 beds. Full air-conditioning |
|
Freezer: |
18 M3 |
|
Cooler: |
18 M3 |
|
Dry PROV.: |
18 M3 |
